Item
活动 |
Symbol
符号 |
Content
详细内容 |
Criterion
标准 |
|
1级过充保护
Over charge 1 Protection |
VCU1 |
1级过充保护电压
Over charge 1” detection voltage |
4.25±0.025V |
|
tCU1 |
Over charge 1st detection delay time
1级过充电检测延迟时间
|
||
|
VCL1 |
Over charge 1st release voltage |
4.00±0.07V |
|
|
Over discharge protection |
VDL |
Over discharge detection voltage
过放电检测电压 |
|
|
tDL |
Over discharge detection delay time |
1±0.3S |
|
|
VDU |
Over discharge release voltage
|
3.00±0.1V |
|
|
持续工作电流
Continue Current |
ICHG |
Continue charge current
不间断续航感应电流 |
20A |
|
IDIS |
Continue discharge current
持继自放电电流大小 |
40A |
|
|
过流保护
Over current protection |
IDIOV1 |
Over current detection current 1
过电流检测电流 1 |
300A±20A |
|
tDIOV1 |
Overcurrent detection delay time 1
过电流保护延时1 |
100±20mS |
|
|
短路保护
Short current protection
|
ISHORT |
Short circuit detection current
短路保护检测电流 |
需客给予手机电池 |
|
tSHORT |
Short circuit delay time
断路维护怎么延时 |
/ |
|
|
过流/短路保护 恢复
Over Short current release
|
/ |
Over current & short current release
过流及短路保护恢复 |
/ |
|
Balance function
平衡功能 |
VBAL |
Balance detection voltage（均衡性办公电阻值） |
/ |
|
Balance release current（平衡电流） |
/ |
||
|
Balance Mode营养均衡办法 |
/ |
Eq Balanced working mode（均衡化起动格局）
|
/ |
|
Internal resistance
保护板内阻 |
RCHG |
Resistance in charge 充电回路内阻 |
<20 mohm |
|
RDIS |
Resistance in discharge 充电回路内阻 |
<20 mohm |
|
|
Current consumption
静态功耗 |
ISTB |
Current consume in normal operation
工作时电路内部消耗 |
<500uA |
组装示意图：
